ELITE PP Series
Coconut Granular Activated Carbon
Elite PP Series is an high activity granular coconut shell activated carbon. It is manufactured by steam activation by selected
high density coconut shell charcoal. An important feature of this series of products is its superior mechanical hardness, density
and extensive de-dusting during its manufacturing that ensures an exceptionally clean activated carbon product.
Elite PP Series is specially designed for organic vapour removal. Due to controlled activation process that yields a very high activity
carbon with a higher than average apparent density, that fulfils the stringent service life requirement. This feature makes the product
ideally suited for use in respirators for personal protection with low pressure drop as additional benefits.
Specifications
| PARAMETERS | TESTING METHOD | GRANULAR ACTIVATED CARBON | ||||
|---|---|---|---|---|---|---|
| PARTICLE SIZE | ASTM D 2862 | 6X12, 8X18, 12x20, 20x50, 30x60 | ||||
| SURFACE AREA | BET | 1450 | 1500 | 1550 | ||
| pH | ASTM D 3838 | 9-11 | 9-11 | 9-11 | ||
| ASH CONTENT | ASTM D 2866 | 3% Max | 3% Max | 3% Max | ||
| MOISTURE | ASTM D 2867 | 3% Max | 3% Max | 3% Max | ||
| IODINE NUMBER | ASTM D 4607 | 1400 | 1450 | 1500 | ||
| APPARENT DENSITY | ASTM D 2854 | 0.410±0.460 | 0.400±0.450 | 0.390±0.450 | ||
| BALL PAN HARDNESS | ASTM D3802 | 97 | 97 | 97 | ||
| CTC Activity | ASTM D3467 | 80 Min | 85 Min | 90 Min | ||
Applications
- Elite PP 80
- Elite PP 85
- Elite PP 90
Features / Benefits
- Coconut Carbon
- High Hardness related to other
raw materials - High Density
- De-dusted Product
- Minimal Attrition, no particle
breakdown - Low Ash
- High adsorption capacity
- Pore structure provides a wide range
of contaminants removal capabilities.
Available Particle Sizes
- 8×30 Mesh (0.60 – 2.36 mm)
- 12×30 (0.425 – 2.36 mm)
- 12×40 (0.425 – 1.70 mm)
- Other granulation available upon request.
Product Quality
- Product is 100% dust free.
- Free of magnetic particles and foreign matter.
- We can adopt any deviations from this quality as per customer requirements.
- Moisture content can be adjusted as per customer requirement.
Standard Packing
- 25 Kg bag (PP Woven Bag)
- 500/550 Kg FIBC Bag
