Gold Recovery
ELITE GS
Coconut Granular Activated Carbon
• Elite GS45 • Elite GS50
• Elite GS55 • Elite GS60
Elite GS product is a coconut shell based granular activated carbon. It is manufactured by steam activation from selected
high-density and good hardness raw material. It is designed and optimized for gold recovery operations. Elite GS was developed
to be a consistent, cost-effective activated carbon that delivers the maximum performance required for gold recovery operations.
For gold recovery circuits, it is essential that the activated carbon employed provides excellent process performance,
minimal attrition loss and minimize maintenance problems. This results in a high resistance to attrition contributing to gold
losses in the circuit and consistently rapid loading
kinetics in the contacting phase.
Specifications
| PARAMETERS | TESTING METHOD | GRANULAR ACTIVATED CARBON | ||||
|---|---|---|---|---|---|---|
| PARTICLE SIZE | ASTM D 2862 | 6X12, 8X16 | ||||
| SURFACE AREA | BET | 1000 | 1050 | 1100 | 1150 | |
| pH | ASTM D 3838 | 6 - 8 | 6 - 8 | 6 - 8 | 6 - 8 | |
| ASH CONTENT | ASTM D 2866 | 3% Max | 3% Max | 3% Max | 3% Max | |
| MOISTURE | ASTM D 2867 | 5% Max | 5% Max | 5% Max | 5% Max | |
| IODINE NUMBER | ASTM D 4607 | 950 | 1000 | 1050 | 1100 | |
| APPARENT DENSITY | ASTM D 2854 | 0.560±0.520 | 0.550±0.520 | 0.540±0.510 | 0.540±0.480 | |
| BALL PAN HARDNESS | ASTM D3802 | 99 Min | 99 Min | 99 Min | 99 Min | |
| CTC | ASTM D3467 | 45 | 50 | 55 | 60/td> | |
| Platelets | AARL | C2 | C2 | C2 | C2 | |
| MPD | 2862 | 72.4 min | 72.4 min | 72.4 min | 72.4 min | |
| Attrition | 2862 | 1.1 Max | 1.1 Max | 1.1 Max | 1.1 Max | |
Applications
- Carbon in Pulp (CIP)
- Carbon in Leach (CIL)
- Carbon Column (CIC)
Features / Benefits
- Coconut Carbon
- High Hardness related to other
raw materials - Highly Abrasion resistance
- Low Platelet Content
- High Microporous structure
- High adsorption capacity
- Low Dust
- Tight Undersize and Screen
Distribution Specification - Easily Regenerated
Available Particle Sizes
- 6×12 Mesh (1.70 – 3.35 mm)
- 8x16Mesh (1.18 – 2.36 mm)
Product Quality
- Product is 100% dust free.
- Free of magnetic particles and foreign matter.
- We can adopt any deviations from this quality as per customer requirements.
- Moisture content can be adjusted as per customer requirement.
Standard Packing
- 25 Kg bag (PP Woven Bag)
- 500/550 Kg FIBC Bag
